| Thermal image and optics | VT08 | VT06 |
| Infrared resolution | 120×90 |
| IR frequency band | 7.5~14 μm(long wave) |
| Frame rate | 9 Hz |
| Thermal sensitivity/NETD | <60 mk |
| Field of view (H x V) | 50° x 37.5° |
| Spatial resolution | 7.6 mrad |
| Focus system | Focus free |
| Minimum focusing distance | 0.5 m (19.7 in) |
| Visible light |
| Visible resolution | 320×240 | NA |
| Visible FOV (H x V) | 53° x 41° | NA |
| Image display and storage |
| Image mode | Thermal image
Visible image
PIP | Thermal image |
| Palettes | Ironbow, Blue-Red, High-Contrast, Amber, Hot Metal, Grayscale |
| Internal storage | >28GB (>100000 images)
*14GB Internal Storage for VT06/VT08 manufactured before 6 Aug 2022. |
| File format | JPEG compression format (.jpg) |
| PIP mode | Yes | No |
| Temperature measurement |
| Temperature range | -20 °C to 400 °C
[-4 °F to 752 °F] (not specified for below -10 °C) |
| Temperature accuracy | ±2°C or 2% @ 23°C±5°C, whichever is greater |
| Emissivity | Adjustable |
| Background temperature compensation | Yes |
| Auto high-/low-temperature capture | Yes |
| Center point temperature | Yes |
| Alarm | Maximum/minimum temperature alarm in full screen |
| Interface and lens |
| Visible lens | Yes | No |
| Flashlight | Yes | No |
| Infrared lens | Yes |
| Laser sighting | Yes |
| Type-C interface | Yes |
| TF card slot | No |
| Tripod interface | Yes |
| Mobile App | No |
| Power system |
| Battery type | Rechargeable Li-ion battery, unremovable |
| Battery operation time | ≥5 hrs (VT08)
≥8 hrs (VT06)
Actual battery life depends on environment and settings |
| Charging Time | <2.5 hrs to full |
| Battery charging temperature | 0 °C to 45 °C |
| Battery charging system | Charge in the machine (the battery is not removable) |
| AC adapter | Include power supply, universal adapter
Output: 5 VDC, 2 A |
| Power saving mode | Yes |
| Environmental specifications |
| Operating temperature | -10 °C to 50 °C |
| Storage temperature | -40 °C to 70 °C |
| Operating altitude | 2000 m (1.24 mi) |
| Storage altitude | 12 000 m (7.5 mi) |
| Others |
| Warranty | 1 year |
| Standard accessories | Wrist strap, quick reference guide, charger + adapter, Type-C data cable, data-downloading card |
| Display | 6.096 cm (2.4-inch) LCD |
| Language | English |
| Size | 20.4 cm x 6.6 cm x 7.6 cm |
| Weight | 0.36 kg | 0.35 kg |
| Relative humidity | ≤90%, non-condensing |
| Safety |
| Safety standards | IEC 61010-1: Pollution Degree 2 |
| Laser | IEC 60825-1: Class 2, 650 nm, <1 mW |
| Battery | IEC 62133-2, UN 38.3 |
| Protection class | IEC 60529: IP65 (with Type-C port closed) |
| Drop test | 2 m |
| Electromagnetic Compatibility (EMC) |
| International | IEC 61326-1: Industrial Electromagnetic Environment
CISPR 11: Group 1, Class A |
